Radial Drilling Machine

Radial Drilling Machine
Radial Drilling Machine
Product Code : 01
Brand Name : KAVERY
Product Description

Following our inception in 1981, we are instrumental in manufacturing, supplying and exporting superior quality Radial Drilling Machine. With its in-depth & precision drilling operations, our machine has revolutionized the industrial works, reducing human intervention in industries while increasing the productivity. Post production, our team of quality controllers checks this machine on various quality parameters to ensure end product meets with international quality standards. Owing to the features like high efficiency & accuracy, longer functional life and low maintenance; our Radial Drilling Machine is highly demanded in the market.



TECHNICAL SPECIFICATION :



Drilling capacity in steel 32.38 1*1/4, 1*1/2
Max dis, spindle centre to column 762 30
Machined area of base 813 x 610 32 x 24
Dia of column 158 6*1/4
Spindle travel 152 6
Max dist, spindle nose to base 914 36
Vertical adjustment of arm 1028 40*1/2
Size of box table 368 x 305 x 305 14*1/2 x 12 x 12
Overall height 1702 67
Floor space occupied 762 x 1295 30 x 51
No. of spindle speeds 8 (gear drive) 8 (gear drive)
Range of spindle speeds 82-2425 82-2425
Spindle bore MT No. 3. M.T. 4 MT No. 3. M.T. 4
Spindle feed by star lever & worm star lever & worm
Drill motor 1 HP. -(1400 rom.) 1 HP. -(1400 rom.)
Elevating motor 0.5 HP. 0.5 HP.
Gross Weight 1000 Kgs. 100 Kgs.
Nett weight 800 Kgs. 800 Kgs.
Case dimensions 950 x 1750 x 1400 950 x 1750 x 1400
